ASW - NAB Metal Hub Adaptor Black (Spindle Screw-on Lock) - NAB-BLK-SL

Technical Specifications:

• Colour: Anodised Silver
• Material: Aluminium
• Hub type: NAB
• Height: 38.5mm (approx.)
• Diameter: 89mm (approx.)
• Trumpet Height (Entire top part): 29mm (approx.)
• Weight: 285 Grams (approx.)

Highlights:

• Fits with most 1/4" tape reel machines with screw-on type lock spindles.
• 3 metal ball plunger added at 120 degrees separation on hum to perfectly centre the spool on to the hub.
• Designed to meet the high expectations of today's tape recorder users.
• Enables the use of NAB Reels on tape machines with screw-on type lock spindle hub.
• The ideal trumpet height.
• Improved thread for simple screwing and unscrewing.
• An additional O-ring to shield the metal spool surface from scratches.
• No plastic parts.
• No complicated locking parts and mechanisms.
• Improved surface quality.
• Precision machining.
• Prongs have been completely modified for better coupling with the reel.
• Improved trident tolerance and spindle shaft hole accuracy.

Applications:

• Reel to reel tape recorders.
• Beautifying R-T-R machines.

Installation Video:

Notes:

• Thin metal reels may require the use of shims (not supplied).
• The price listed is for a single piece of NAB adaptor.
• Country of Origin: INDIA.
